INl Rei sumus inter artifices professionales et quales artifices hydraulicos in Sinis.
Motores magna pressura, alta velocitas coegi, et valvulae trutina;
Hoc est summus onus conditionibus disposito
Est optima solutio pro 6 ad 50-ton excavatoris hydrau
Efficiens et pacto
Summus pressura technology auget efficientiam systematis hydrau
Duo-celeritate motricium cum valvula integrata statera et pressura subsidio valvae
Motricium munus brakingi hydraulicum integrat
Celeritas statim mutari potest ad petitionem
Humilis temperatus, summus efficientiae
Temperatus range operans: -20° C~ 80° C
Foedus design
Humilis obsessio motorum summus pressio servitutem extendit ad vitam principalium partium et totam augendam
Durabilitas systematis
Omnes-aeris liner ad hydrau Poopus rotationis
Duplex metallum (aeris / chalybe) distribution lance
Gyratio cum speciali veris systematis vitam motoris auget
Triplex signandi ratio reducendi: labyrinthum mechanicum sigillum, sigillum oleum V-typus, sigillum oleum principale.
Sigillum oleum principale reponi potest sine redactore disassemble
Partes reducentis partes independentes sunt, faciles inaugurari et plene praebere possunt pro oneribus negativis
ITM01:
| Modal | (L/min) | (ML/r) | (Mpa) | (Mpa) | Ratio calces | (N.m) | (r/min) | gyratio | (℃) | (mm2/s) |
| ITM01 | 20 | 6.31/12.56 | 25 | 2-7 | 36.96 | 1845 | 85.8/43 | bidirectional | -20- 80 | 16-25 |
| Modal | (L/min) | (ML/r) | (Mpa) | (Mpa) | Ratio calces | (N.m) | (r/min) | gyratio | (℃) | (mm2/s) |
| ITM03 | 40 | 12/18 | 21 | 2-7 | 45.2 | 2719 | 55/37 | bidirectional | -20- 80 | 16-25 |
ITM04：
| Modal | (L/min) | (ML/r) Motor | (Mpa) | (Mpa) | Ratio calces | (N.m) | (r/min) | gyratio | (℃) oleum | (mm2/s) |
| ITM04 | 40 | 14.3/23.6 | 21 | 2-7 | 52.7 | 4200 | 55/33 | bidirectional | -20- 80 | 16-25 |
| Modal | (L/min) Input flow | (ML/r) | (Mpa) | (Mpa) | Ratio calces | (N.m) | (r/min) | gyratio | (℃) | (mm2/s) |
| ITM06 | 50 | 19/34 | 24.5 | 2-7 | 47.53 | 6300 | 55/30 | bidirectional | -20- 80 | 16-25 |
| Modal | (L/min) Input flow | (ML/r) | (Mpa) Operationis Pressura | (Mpa) | Ratio calces | (N.m) | (r/min) | gyratio | (℃) oleum | (mm2/s) |
| ITM07 | 50 | 22/44 | 27.5 | 2-7 | 53.706 | 10500 | 50/25 | bidirectional | -20- 80 | 16-25 |
ITM09:
| Modal | (L/min) | (ML/r) | (Mpa) | (Mpa) | Ratio calces | (N.m) | (r/min) | gyratio | (℃) | (mm2/s) |
| ITM09 | 80 | 34/53 | 30 | 2-7 | 53.7 | 11500 | 51/33 | bidirectional | -20- 80 | 16-25 |
| Modal | (L/min) | (ML/r) | (Mpa) | (Mpa) | Ratio calces | (N.m) | (r/min) | gyratio | (℃) | (mm2/s) |
| ITM10 | 80 | 38/65 | 25 | 2-7 | 53.7 | 13000 | 51/33 | bidirectional | -20- 80 | 16-25 |
| Modal | (L/min) | (ML/r) | (Mpa) | (Mpa) | Ratio calces | (N.m) | (r/min) | gyratio | (℃) | (mm2/s) |
| ITM18 | 130 | 43/67 | 30 | 2-7 | 53 | 16900 | 57/37 | bidirectional | -20- 80 | 16-25 |
| Modal | (L/min) | (ML/r) | (Mpa) | (Mpa) | Ratio calces | (N.m) | (r/min) | gyratio | (℃) | (mm2/s) | Lorem exempla |
| ITM22 | 130 | 48/81 | 34.3 | 2-7 | 53.7 | 23700 | 50/30 | bidirectional | -20- 80 | 16-25 | 13-17 |
| Modal | (L/min) | (ML/r) | (Mpa) | (Mpa) | Ratio calces | (N.m) | (r/min) Theoretical | gyratio | (℃) | (mm2/s) |
| ITM40 | 230 | 99/147 | 34.3 | 2-7 | 50.5 | 40546 | 50/32 | bidirectional | -20- 80 | 16-25 |
| Modal | (L/min) | (ML/r) | (Mpa) | (Mpa) | Ratio calces | (N.m) | (r/min) | gyratio | (℃) | (mm2/s) |
| ITM60 | 330 | 195/120 | 34.3 | 2-7 | 63.84 | 67000 | 40/26 | bidirectional | -20- 80 | 16-25 |
Producta comparata ab inceptis claris ab usoribus penitus creditae sunt.
Annos Industry Usus
Factory Area
Doctus Employees
Provectus Productio Linea
INI Hydraulic Co., Ltd. hydraulic winches, hydraulic motoribus et planetarum inter viginti annos specialisati sunt. We are one of the professional Construction Machinery Accessory Suppliers in Asia. Customizing to optimize customers' ingenious equipment designs is our way to stay alive robustly in the market. Over 26 years, driven by the commitment of always innovating to satisfy customers' needs, we have developed a wide range of product lines based on our self-developed technologies. The wide spectrum of products, each correlating intimately, contains hydraulic and electric winches, planetary gearboxes, slewing drives, transmission drives, hydraulic motors, pumps and hydraulic systems.
Fiducia productorum nostrorum valde in variis applicationibus probata est, non limitata machinae industriae, machinae constructionis, machinae navis & ornatae, apparatum littus, fodienda et metallurgica machina.
Praeterea productum qualitas nostra per plures terrarum inclitorum corporum testimonium approbata est. Testimonia, quae fructus nostri consecuti sunt, includunt EC-Type Examinationis certificatorium, BV INSTITUTUM, DNV GL Certificate, EC Attestationis Conformitatis, certificatorium Type Approval pro Marine Product et Lloyd's Register Quality Assurance. Hactenus, praeter Sinas, mercatum nostrum domesticum, fructus nostros late exportavimus in Civitatibus Foederatis, Germania, Nederlandia, Australia, Russia, Turcia, Singapore, Iaponia, Corea Meridiana, Malaysia, Vietnam, India et Irania. Logistics et post-venditio officia nostra totum mundum prompte et fideliter operiunt de profundis clientibus nostris.
Fructus nostri consecuti sunt, includuntur EXAMINATIO EC-Type certificatorium, BV, INSTITUTUM, DNV, GL Certificate, EC Conformitatis testimonium, certificatorium Type Approval pro Marine Product et Lloyd's Register Quality Assurance.
